Antenna Toknav TSA1000 GPS GNSS

Four-system full-frequency high-precision GNSS Antenna
The TSA1000 is an external measurement antenna that covers GPS, GLONASS, BDS, and GALILEO, providing compatibility with multiple systems for current measurement devices. It can be widely used in various applications such as land surveying, marine measurement, channel measurement, dredging measurement, seismic monitoring, bridge deformation monitoring, landslide monitoring, and automated operations at docks.

• Four-system full-frequency coverage
• IP67 ruggedized design
• Millimeter-level accuracy
• High phase center stability
• Strong anti-interference performance

Feature :

• GNSS Tracking : GPS, GLONASS, BDS, GALILEO, QZSS, SBAS and IRNSS
• Axial Ratio : 3dB
• LNA Gain : 40dB (typical)
• Humidity : 95% non-condensing
• Protection : IP67
• Size : Φ152mm*62.2mm
• Weight : 500g
