iMex Suparule 600 Cable Height Meter

• The Suparule range of cable height meters comes with various options to meet your requirements. The Supa600 measures up to six wires with up to 15m height measurement.
• A great alternative to telescopic measuring rods, the cable height meter is used by line operators within a utilities industry such as telecommunications and electricity.
• This instrument operates by emitting short sound bursts and calculating the elapsed time for the sound to be reflected from the cable back to the CHM600. These results can then be displayed in either imperial or metric units
• Measure cables up to 15m high
• Wires to 150mm apart

Specifications:

Accuracy: 0.5% ± 2 digits
Resolution (range <10m): 5m
Resolution (range <10m): 10mm
Minimum gap between wires: 150mm
Operating Temperature Range: -10° C to 40° C
Meausurement Units: Imperial or metric
Auto power off delay: 3 mins
Dimensions (L x W x H): 205mm x 100mm x 70mm
Weight: 0.5kg
