Deskripsi Produk
AIRFRAME
| Max Diagonal Wheelbase | 1883 mm |
|---|---|
| Dimensions | 2509×2213×732 mm (Arms and propellers unfolded) 1795×1510×732 mm (Arms unfolded and propellers folded) 1100×570×732 mm (Arms and propellers folded) |
SPRAYING SYSTEM- SPRAY TANK
| Volume | Rated: 15 L, Full: 16 L |
|---|---|
| Operating Payload | Rated: 15 kg, Full: 16 kg |
SPRAYING SYSTEM - NOZZLE
| Model | XR11001VS (Standard), XR110015VS (Optional, purchase separately) |
|---|---|
| Quantity | 8 |
| Max Spray Rate | XR11001VS: 3.6 L/min, XR110015VS: 4.8 L/min |
| Spray Width | 4-6.5 m (8 nozzles, at a height of 1.5-3 m above crops) |
| Droplet Size | XR11001VS：130 - 250 μm XR110015VS：170 - 265 μm (Subject to operating environment and spray rate) |
SPRAYING SYSTEM - FLOW METER
| Measurement Range | 0.45-5 L/min |
|---|---|
| Error | < ±2% |
| Measurable Liquid | CConductivity > 50 mS/cm (Liquids such as water or pesticides that contains water) |
FLIGHT PARAMETERS
| Operating Frequency | 2.4000 GHz-2.4835 GHz 5.725 GHz-5.850 GHz * |
|---|---|
| EIRP | 2.4 GHz SRRC/ CE / MIC/ KCC: < 20 dBm FCC / NCC: < 26 dBm 5.8 GHz SRRC/ NCC/ FCC: < 26 dBm |
| Total Weight (Excluding battery) | 18.5 kg |
| Standard Takeoff Weight | 41 kg |
| Max Takeoff Weight | 42 kg (At sea level) |
| Max Thrust-Weight Ratio | 2.05 (Takeoff weight of 39.5 kg) |
| Hovering Accuracy (With strong GNSS signal) | D-RTK enabled: Horizontal: ±10 cm, Vertical: ±10 cm D-RTK disabled: Horizontal: ±0.6 m, Vertical: ±0.3 m (Radar module enabled: ±0.1 m) |
| RTK/ GNSS Operating Frequency | RTK: GPS L1/L2, GLONASS F1/F2, BeiDou B1/B2, Galileo E1/E5 GNSS: GPS L1, GLONASS F1, Galileo E1 |
| Battery | DJI-approved battery pack (AB2-17500mAh-51.8V) |
| Max Power Consumption | 5600 W |
| Hovering Power Consumption | 4600 W (Takeoff weight of 39.5 kg) |
| Hovering Time** | 18 min (Takeoff weight of 24.5 kg with a 17500 mAh battery) 10 min (Takeoff weight of 39.5 kg with a 17500 mAh battery) |
| Max Pitch Angle | 15° |
| Max Operating Speed | 7 m/s |
| Max Flying Speed | 10 m/s (With strong GNSS signal) |
| Max Wind Resistance | 8 m/s |
| Max Service Ceiling Above Sea Level | 2000 m |
| Recommended Operating Temperature | 0° to 40°C (32° to 104°F) |
| * To comply with local laws and regulations, this frequency is not available in some countries or regions. ** Hovering time acquired at sea level with wind speeds lower than 3 m/s. |
FPV CAMERA
| FOV | Horizontal: 98°, Vertical: 78° |
|---|---|
| Resolution | 1280×960 30 fps |
| FPV Spotlight | FOV: 110°, Max brightness: 12 lux at 5 m of direct light |
DBF IMAGING RADAR
| Model | RD2418R |
|---|---|
| Operating Frequency | SRRC (China)/ CE (Europe)/ FCC (United States): 24.00 GHz-24.25 GHz |
| Power Consumption | MIC (Japan) / KCC (Korea): 24.05 GHz-24.25 GHz |
| EIRP | 15 W |
| Altitude Detection & Terrain Follow* | MIC/ KCC/ CE/ FCC: 20 dBm |
| Obstacle Avoidance System* | Altitude detection range: 1-30 m |
| IP Rating | Stabilization working range: 1.5-15 m |
| *The effective radar range varies depending on the material, position, shape, and other properties of the obstacle. |
PROPULSION SYSTEM - MOTOR
| Stator Size | 100×15 mm |
|---|---|
| KV | 75 rpm/V |
| Max Thrust | 13.5 kg/rotor |
| Max Power | 2400 W/rotor |
| Weight | 616 g |
PROPULSION SYSTEM - FOLDABLE PROPELLERS (R3390)
| Diameter × Pitch | 33×9 in |
|---|---|
| Weight (Single propeller) | 90 g |
PROPULSION SYSTEM - ESC
| Max Working Current (Continuous) | 40 A |
|---|---|
| Max Working Voltage | 58.8 V (14S LiPo) |
REMOTE CONTROLLER
| Model | GL300N |
|---|---|
| Operating Frequency | 2.4000 GHz-2.4835 GHz 5.725 GHz- 5.850 GHz* |
| Effective Transmission Distance (Unobstructed, free of interference) | SRRC/ MIC/ KCC/ CE: 3 km NCC/ FCC: 5 km |
| EIRP | 2.4 GHz SRRC/ CE/ MIC/ KCC: < 20 dBm FCC / NCC: < 26 dBm 5.8 GHz SRRC/ NCC/ FCC: < 26 dBm |
| Display | 5.5-inch screen, 1920×1080, 1000 cd/m2, Android system 4G RAM＋16G ROM storage |
| Power Consumption | 16 W (Typical value) |
| Operating Temperature | -10° to 40°C (14° to 104°F) |
| Storage Temperature | Less than 3 months: -20° to 45°C (68° to 113°F) More than 3 months: 22° to 28°C (70° to 82°F) |
| Charging Temperature | 5° to 40°C (40° to 104°F) |
| * To comply with local laws and regulations, this frequency is not available in some countries or regions. |
REMOTE CONTROLLER INTELLIGENT BATTERY
| Model | WB37-4920mAh-7.6V |
|---|---|
| Battery Type | 2S LiPo |
| Capacity | 4920 mAh |
| Voltage | 7.6 V |
| Energy | 37.39 Wh |
| Charging Temperature | 5° to 40°C (40° to 104°F) |
REMOTE CONTROLLER CHARGING HUB
| Model | WCH2 |
|---|---|
| Input Voltage | 17.3-26.2 V |
| Output Voltage and Current | 8.7 V, 6 A |
| Operating Temperature | 5° to 40°C (40° to 104°F) |
REMOTE CONTROLLER POWER ADAPTER
| Model | A14-057N1A |
|---|---|
| Input Voltage | 100-240 V, 50/60 Hz |
| Output Voltage | 17.4 V |
| Rated Power | 57 W |
* Harga tidak termasuk Charger & Baterai
